SKF Compatible Data Collector Connectors
Indicative price, ex-works. Excludes GST, packing & forwarding, freight, insurance and duties. Request a quotation to confirm.
CTC is proud to offer a selection of SKF-compatible data collector connectors designed for use with popular SKF CMVA Series, SKF CMXA Series, SKF Microlog, DLI/DCA, and DLI/DCA-31 data collector models.
CTC is proud to offer a selection of SKF-compatible data collector connectors designed for use with popular SKF CMVA Series, SKF CMXA Series, SKF Microlog, DLI/DCA, and DLI/DCA-31 data collector… Read more
models.Models in the SKF Compatible Data Collector Connectors family
| Part number | Description | Connector Type | Connector Insert Material | Connector (Non-Integral) | Application | Availability |
|---|---|---|---|---|---|---|
| C4 | SKF CMVA Series Compatible, 25 Pin D Subminiature Connector, Single Axis Acceleration Input | 25 Pin Subminiature | Steel | — | Portable Monitoring | Built to order |
| C66 | SKF CMXA Series, SKF dBx CMVA90, and Azima DLI/DCA Compatible 6 Pin Fischer Connector, Single Channel Acceleration Input, Pin 1 Signal/Power (+), Pin 5 Common (-) | 6 Pin Fischer® connector | PEEK | — | Portable Monitoring | Built to order |
| C325 | SKF dBx CMVA90 and Azima DLI/DCA-31 Compatible, 6 Pin Fischer Connector, Triaxial Acceleration Input, Pin 1 (Y Axis), Pin 2 (X Axis), Pin 5 Common (-), Pin 6 (Z Axis) | 6 Pin Fischer Connector | PEEK | — | Portable Measurements | Built to order |
| C364 | SKF Microlog and dBx CMVA90 Compatible, 7 Pin Fischer Connector, Single Channel Tachometer Input, Pin 4 Common (-), Pin 6 Signal/Power (+) | 7 Pin Fischer | PEEK | — | Portable Monitoring | Built to order |
| C484 | SKF dBx CMVA90 and Azima DLI/DCA-31 Compatible, 6 Pin Fischer Connector, Triaxial Acceleration Input, Pin 1 (X Axis), Pin 2 (Y Axis), Pin 5 Common (-), Pin 6 (Z Axis) | 6 Pin Fischer Connector | PEEK | — | Portable Measurements | Built to order |
| C516 | SKF CMXA, SKF dBx CMVA90, and Azima DLI/DCA Series Compatible, 6 Socket Fischer® Connector, Wired to mate with C66 (6 Pin Fischer®), Single Channel Acceleration Input | 6 Socket Fischer® Connector | PEEK | — | Portable Monitoring | Built to order |
| F | Molded BNC Plug Connector, 250 °F (121 °C) Max Temp | Molded BNC Plug | Teflon® | — | Portable Measurements, Permanent Mount | Built to order |
| C690 | SKF CMXA Series, SKF dBx CMVA 90 Compatible 6 Pin Fischer Connector, Dual Output Vibration and Temperature, Pin 1 Vibration (+), Pin 4 Temperature (+), Pin 5 Common (-) | — | — | 6 Pin Fischer® connector | — | — |
Models covered
Available options include single channel acceleration input, single channel tachometer input, and triaxial acceleration input. Create a SKF Microlog dBX Single Channel Input Cable by configuring our F connector (BNC Plug) with K2C or D2C connectors (2 Pin MIL Style Connectors) on the cabling of your choice: CB103-K2C-XXX-F-SF CB104-D2C-XXX-F-SF (Please note, F connectors must be selected as connector #2 when creating your cordset in the cable wizard) Build your perfect SKF-compatible data collector connector and cable assembly with our easy-to-use Custom Cable Wizard that takes the guesswork out of choosing compatible hardware for your assembly.
Features
From the C4 datasheet; the other part numbers in this family differ.
- For use with SKF acceleration input, CMVA series
Choosing a part number
This family covers 8 part numbers. They share the specification in the Specs tab and differ in the details set out in the model table — most often the connector, the exit direction and the mounting thread. Tell us the machine and the measurement and we will confirm the part number.
Where CTC publishes a stock tag for a part number it is shown in the Availability column — Stock or Built to order. Built to order is normal for a configured sensor and is not a shortage; it sets lead time, which we confirm with the quotation.
CTC lists C66 as a best seller in this family.
Supply and support
Supplied and supported in India by TIERA, authorised distributor for CTC (Connection Technology Center, USA). Each unit ships with CTC’s own calibration certificate. Pricing and lead time on request.
